LIFTO
ADJUSTABLE PEDESTAL
Description
The adjustable X-base plate pedestal of the LIFTO is sturdy and secure once in position. The height adjustment can be can be extended by simply inserting adapters increasing the range permitting more flexibility during the installation process.
Overview
| Height range: | 35 - 55 mm ǀ 55 - 95 mm ǀ 95 - 135 mm ǀ max. 295 mm |
| Adapter A20: | +20 mm |
| Adapter A40: | +40 mm |
| Adapter A60: | +60 mm |
| Adapter A80: | +80 mm |
Dimensions: | Baseplate Ø 167 mm ǀ 70 mm support plate diameter |
Material: | PP polypropylene Recycled black ǀ UV and weather resistant |
Accessories: | UNIA 4.2 x 22 mm for fastening the pedestals to a wooden or aluminium substructure RELO A adapter for screwless fastening of the pedestals to RELO substructure joists GUMO LGD/LGA pressure distribution pad for flat roof / LGA for aluminium foil |
HIGHLIGHTS
The X-shaped base plate is variable in position and secure in situe
Integrated RELO A attachment
The height adjustment can be continuously increased using intermediate adapters permitting a versatile height range
All highlights in the video
