TRIGO
ADJUSTING WEDGE
Description
The wedge shape of the TRIGO adjustment wedges guarantees easy and quick set-up of terrace substructures made of wood, wood-like materials or aluminium. Three adjustment wedges can compensate for differences in height from 14 mm to 67 mm. The design of the staggered teeth ensures a non-slip and deformation-free connection.
Overview
| Height range: | 14 - 67 mm Depending on the width of the substructure |
| Dimensions TRIGO T14: | H 3,5 – 14 mm ǀ W 46 mm ǀ L 93 mm |
| Dimensions TRIGO T23: | H 4 – 23 mm ǀ W 46 mm ǀ L 152 mm |
| Dimensions TRIGO T50: | H 31 – 50 mm ǀ W 46 mm ǀ L 152 mm |
| Material: | PE polypropylene Recycled black ǀ UV and weather resistant |
HIGHLIGHTS
TRIGO
compatible adjustment wedges allow a continuous height adjustment up to 67 mm
TRIGO
The adjustment wedges are universally applied and can be combined
TRIGO
The special design ensures maximum load transfer without deformation
TRIGO
All highlights in the video
