ZONA
WPC DECKING CONNECTOR
Description
The ZONA stainless steel decking connector guarantees easy, fast and uncomplicated assembly. Two parallel-guided mounting zones ensure a trouble-free decking connection, it creates an additional ventilation level, prevents protruding screw heads and allow mounting to metal substructures.
Overview
| Fixing: | concealed system |
| Fixing type: | sliding point - sliding point |
| Joint distance: | 3,0 mm |
| Decking board: | For composite boards with lateral side grooves |
| Dimensions: | B 42 mm | W 30 mm | H 4,6 mm |
| Start- End connector: | B 31 mm | W 22 mm | H 4,6 mm |
| Material: | Stainless steel A2 |
| UNIA drilling capacity: | ca. 3 mm thick Aluminium |
| Special feature: | 2 mounting zones |
HIGHLIGHTS
ZONA
Integrated ventilation base plate for a constructive protection
ZONA
Compatible start and end connectors
ZONA
Fastening zone for the decking connection allows the boards to be inserted without any problems
